Dressel Lamp Catalog Pages: Tail Lamps

Following are scans of a lamp catalog from the Dressel Railway Lamp and Signal Company of Arington, New Jersey. The catalog is marked Bulletin TL-170 "Tail Lamps". The publishing date of the catalog is unknown, although the use of a "tall-globe" lantern as a tail lamp (last page) suggests that it dates to the 'teens or more likely the 1920's. Scans are shown in the order shown in the original catalog, which does not follow the numerical order of the model numbers. Click on the thumbnails to see readable pages. In order to allow readability, scans are very large and may take some time to download on a modem connection. Use your browser's [BACK] button to get back to this page. See note below about image resizing.

#166 Tail Marker Lamp #1166 Electric Tail Marker Lamp #169 Tail Marker Lamp #170 Tail Marker Lamp #171 Tail Marker Lamp
#1470 ARA Tail Marker Lamp #38 Tail Marker Lamp #38-A Tail Marker Lamp #38-B Tail Marker Lamp #167 Tail Marker Lamp
#178 Combination Tail and Route Signal Lamp #302 Route Signal Tail Marker Lamp #185 Mine Tail Lamp #220 Motor Car Tail Lamp #251 Tail Lamp

  #311 Fresnel Tail Lamp #15 Tail Lamp #30 Revolving Deck Caboose Lamp

  #210 Automatic Deck Caboose Lamp #5-A Platform Tail Lamp #1150 Steel Guard Tail Lantern

Note: If you use Internet Explorer and have "automatic image resizing" turned on, the larger scans may shrink to the size of your browser window, which will probably make the print unreadable. To turn this off, go to [Tools] [Internet Options] [Advanced], scroll down to the Multimedia section, and uncheck "Enable Automatic Image Resizing". Click [Apply].
